TrophySeeker

Just an FYI. Those headings don't show up in the mobile app which many of us use almost exclusively... Sent from my SM-G955U using Lake Ontario United mobile app

Unfortunately I believe Warrens went out of business. Sent from my SM-G955U using Lake Ontario United mobile app

Shaft on paddle wheel bent? Sent from my SM-G955U using Lake Ontario United mobile app

I'm not a Mercury guy but I think the 2 in your part number indicates 25" shaft. Sent from my SM-G955U using Lake Ontario United mobile app

That was the first image I found online. Obviously in your case the charger box at the top is your 24v motor. That should give you a full day of Auto pilot! Good luck! Sent from my SM-G955U using Lake Ontario United mobile app

I thought you were looking to do this: Sent from my SM-G955U using Lake Ontario United mobile app

FYI. This is the product I use on my walleye boat. I use the combiner 100 and trollbridge 24 to charge all 3 of my batteries from the motor alternator or a single bank charger when back on land. http://www.yandina.com/combInfo.htm Sent from my SM-G955U using Lake Ontario United mobile app

There have been a lot of trolling motors for sale on here. It took me almost 2 years to sell mine at about half price of what i thought was a fair starting price. Be patient. Sent from my SM-G955U using Lake Ontario United mobile app

Wow. That looks like you have the wrong shaft length motor installed. What is the measurement from the keel to the top of the transom? The motor part number will decode shaft length. BTW, your first photo shows the kicker mounted port side, but I don't think that is your problem. Sent from my SM-G955U using Lake Ontario United mobile app

This actually isn't true. 2 batteries in series give you 24v. Two batteries in parallel are still 12v with double the current. Two 24v batteries (which are really two 12v batteries in series) in parallel is still 24v, just double the current of first pair. Not sure how you would have room for that but simple enough to wire if you want. Charging from the kicker won't work while the trolling motor is in use because the output is about 13.8v. There is a way to do this with a smart relay but not when the batteries are in use at 24v. Sent from my SM-G955U using Lake Ontario United mobile app

It sounds like you are looking to mount a 15A shore power inlet. 30A twist lock is more common for shore power. In either case I personally would not drill through the exerior of the boat for that. Mounting inside the cockpit would be preferable. Sent from my SM-G955U using Lake Ontario United mobile app

Track won't fit without more holes or a transition plate, which will not be a standard item. The only product i know of that will fit is the dual holder shown by decoy. Sent from my SM-G955U using Lake Ontario United mobile app

Why not mount a short section of Cannon or Berts track to the mount and then just slide the holders in? Sent from my SM-G955U using Lake Ontario United mobile app

The base is designed to be between the big body mount and the swivel base as in Decoy Hound's picture. Is that where you are placing it? Sent from my SM-G955U using Lake Ontario United mobile app

Typically 24V is 70 lb... Sent from my SM-G955U using Lake Ontario United mobile app
