SweepN

Cannon downrigger on cannon track system.

Recommended Posts

Thinking about using cannon track system to mount my cannon downriggers..Anyone have any pros or cons to offer me?

Share this post


Link to post
Share on other sites

What type of boat are you mounting to? Good idea to use a backing plate on the underside to distribute stress. Do not use screws, bolt through, use S/S.

There is an incredible amount of stress on the swivel, mounting pedestal and Gunwhale or whatever your mounting to. Have also heard of bracket or swivel failures.

It is good idea to tether the downrigger with strap or aircraft cable to an independent eye bolt.

The power cable may save you, but who would want to count on that to save your $500+ investment.

On my 16 alum. there was some sideways flex so I added a gusset brace.

Cannon downrigger gusset 001.JPG

Cannon downrigger gusset 003.JPG

Cannon downrigger gusset 006.JPG

Share this post


Link to post
Share on other sites

I have a fiberglass boat with no access underneath. .There is no way to nut and bolt it..very informative pics..

Share this post


Link to post
Share on other sites

Did you use 6 inch mounts? I was thinking the shorter the better. .

Share this post


Link to post
Share on other sites

I used 6" to give a little more clearance over my kicker motor. There is not much flex long ways, but there is side to side. If you can only screw from top. I would investigate other options, like mounting the track to a larger piece of alum plate, longer/wider. with more screws to distribute the stresses. Scotty make this "d" mount. Just imagine an 8-10lb cannon ball bouncing on a choppy day. lol

Or heaven forbid you snag something.



Share this post


Link to post
Share on other sites

Thanks for the great advice!  Very much appreciated. .
