Hydrofoil recommendations

Recommended Posts

Your boat will be up on plane sooner.

Edited by MCF

Share this post


Link to post
Share on other sites

What helped me more then the hydrofoil is trim tabs, my Sea Ray took forever to get on plane with the nose up in the air I couldn’t see for a long time. I added trim tabs now she hops on plane and can trim it to where I want it. JMO....

Share this post


Link to post
Share on other sites

I have used them and they do help but on a 15 hp suzuki outboard that i tried one on  it robbed the water to the water pump and burned the pump out and on my big boat it helps it get on plain but still not happy with results just bought a pair of sx smart taps ck them out i think they will do the trick and pretty fair priced as well.

Share this post


Link to post
Share on other sites

I have one on my aluminum 17 footer on a 70hp outboard. It helped a lot but I never needed it before I hung a kicker on the back. Can you distribute your weight forward more? I ended up moving my gas tank to the front of the boat and moving my console forward about a foot any way because I couldn’t fish in the wind.. my front was way too light and it blew all over the place at walleye trolling speeds. Now that I moved everything I probably don’t need the hydrofoil. Just a thought?


Sent from my iPad using Lake Ontario United

Share this post


Link to post
Share on other sites

If it is a 19 footer you can probably get away with just a hydrofoil. If it is 22 foot, go for a hydrofoil and trim tabs. either way you will have to play with your lower unit angle to make it work.

Share this post


Link to post
Share on other sites

I’ve got tabs on the back but with a 15 horse four stroke kicker on a 19 foot islander the front and goes right up in the air I figured the foil would help





Sent from my iPhone using Lake Ontario United



Share this post


Link to post
Share on other sites

We've got one on the 175hp outboard on our islander.  I can't tell you if it helps much since I've never had the boat on water without one but our boat pops up on plane fast and gives me lots of range (speed and boat orientation) using the trim.  The boat will hold on plane down to roughly 13 mph.  Down the road I'll probably add trim tabs but for what a hydrofoil costs I don't think you could go wrong.

Share this post


Link to post
Share on other sites

After installing a Trolling motor And Bracket that weighted about  200 lbs on my 21 ft. the trim tabs didn't  quite do it . Added  Hydra foils  [ 150 hp. outboard ] and a Couple 25 lb. bags of lead shot in the bow , PERFECT ,  Gets up and rides like a charm.

Share this post


Link to post
Share on other sites

Any one have any brand names in mind ? And thanks for all the help.

Share this post


Link to post
Share on other sites

 I Had Davis Doel Fin on Two boats so that is the only one I am familiar with . there might be another brand that is better ???? . Would be nice to find a test with different brand hydafoils used on one boat .

Share this post


Link to post
Share on other sites
